Place of Origin:
Sichuan, China
Brand Name:
TRAIRF
Contact Us
TR-Floor Filter Parameter Sheet |
||||
Model |
TR-Floor Filter 1'' |
TR-Floor Filter 2'' |
TR-Floor Filter 3'' |
TR-Floor-Filter 4'' |
Weight |
150-160gr/s qm |
200-210gr/s qm |
240gr/s qm |
320gr/s qm |
Thickness |
30mm |
50mm |
70mm |
100mm |
Rated Air Flow |
3780m³/h |
3280m³/h |
3780m³/h |
41m³/h |
Initial Resistance |
15Pa |
15Pa |
15Pa |
15Pa |
Final Resistance |
180Pa |
230Pa |
250Pa |
250Pa |
Medium Resistance |
76.60% |
76.60% |
76.60% |
76.60% |
Air Velocity |
1.05m/s |
1.5m/s |
1.05m/s |
0.65m/s |
Dust Holding |
2430gr/s qm |
3930gr/s qm |
4330gr/s qm |
7350gr/s qm |
Max Temperature |
180℃ |
180℃ |
180℃ |
180℃ |
Filtration Class |
G2(DIN24185) |
G3(DIN24185) |
G3(DIN24185) |
G4(DIN24185) |
Flame Resistance |
F-1(DIN53438) |
F-1(DIN53438) |
F-1(DIN53438) |
F-1(DIN53438) |
Specification
item |
value |
Applicable Industries |
Manufacturing Plant |
Video outgoing-inspection |
Provided |
Machinery Test Report |
Provided |
Warranty of core components |
Not Available |
Condition |
New |
Efficiency |
99% |
Construction |
roll |
Porosity |
5 Micron |
Place of Origin |
China |
Province |
Sichuan |
Brand Name |
TRAIRF |
Dimension(L*W*H) |
20M*1M*50mm |
Weight |
2.5KG |
Warranty |
Unavailable |
Filtration Grade |
G4 |
Type |
Rolls or Slices |
Color |
White and Green |
Material |
Glass Fiber |
Normal Size |
1*20M*50/60 mm |
Initial Pressure |
15 Pa |
