Advantages
* FFU provides high quality clean air for different areas, different clean rooms and micro-environments. In the new clean room, clean workshop or renovation, it can not only improve the cleanliness level, reduce noise and reduce vibration, but also greatly reduce the cost. Easy to install and
maintain, it is an ideal part for clean environment.,
* The shell structure is made of high quality aluminum zinc plate, light weight, corrosion resistance, rust resistance, beautiful and generous.
* FFU laminar flow cover is in accordance with the American federal standard 209E, METOME dust particle counter scanning detection one by one, to ensure quality.
Specification:
1.Dimension: 570*570*340mm
2.Air Filter Size: 570*570*69
3.Air Volume: 700-1800 m³/h
4.External Static Pressure: 98Pa
5.Power Supply Standard: 220V
6.Filter Efficiency:≥99.9995% @≥0.3μm
7.Shock: ≤0.4m/s2
8.Noise:≤55Db(a)
9.Main body material: stainless steel, aluminum alloy, galvanized plate
|
Model Parameters |
TR-FFU-F1 |
TR-FFU-F2 |
TR-FFU-F3 |
TR-FFU-F4 |
|||
|
TR-FFU-F1X |
TR-FFU-F2X |
TR-FFU-F3X |
TR-FFU-F4X |
||||
|
Nominal volume (m³/h) |
2000 |
1800 |
1000 |
900 |
|||
|
NoiseDb(A) |
54~60 |
||||||
|
Hepa filter efficiency |
≥99.99% ~ 99.9995%( @≥0.3μm) |
||||||
|
Power |
AC220V±10%,1φ,50HZ±2HZ |
||||||
|
The input power (W) |
180 |
180 |
145 |
75 |
|||
|
Envelop dimensions (mm)L*W*H |
1220*610*390 |
1170*570*340 |
610*610*390 |
570*570*340 |
|||
|
Hepa filter specifications (mm) |
1220*610*69 |
1170*570*69 |
610*610*69 |
570*570*69 |
|||
|
Coarse efficiency filters specifications (mm) |
495*495*21 |
495*495*21 |
395*395*21 |
395*395*21 |
|||
Customized Service is Available
