Place of Origin:
Sichuan, China
Brand Name:
TRAIRF
Contact Us
Carbon filtering is a method of filtering that uses a piece of activated carbon to remove contaminants and impurities, utilizing chemical adsorption. When a material adsorbs something, it attaches to it by chemical attraction. The huge surface area of activated charcoal gives it countless bonding sites. When certain chemicals pass next to the carbon surface, they attach to the surface and are trapped.
1.Aluminum alloy frame is strong enough to protect the whole bag filter.
2.Non-woven fabric has good flexibility and mechanical strength,is recycable and environmental friendly.
3.Active Carbon has strong adsorption ability,can remove odour effectively.
4.The formation of fine workmanship, double take the lineto make quality more guaranteed
Product Materials, features, specifications
* Excellent absorption efficiency,
* large ventilation,
* dismountable frame design (activated carbon is changeable),
* dimension can be customized.
* Media of high quality activated carbon Reliable performance and proven high adsorption capacity
* Variety of carbon grades available
* Maximum media utilization for longer lifetime of sorbent charge
* Longer life cycle operating and lower maintenance costs (LLC)
The frame is adopted of high quality galvanized plate with stainless steel mesh or galvanized mesh welded on the frame as the both sides meshes.
Inside mesh is adopted of metal filter mesh or activated carbon nonwoven cloth, activated carbon powder is filled in the middle(prismatical activated carbon or coconut activated carbon powder).
| Model | Outside Dimensions(mm) | Rated Air Flow(m³/h) | Initial Resistance(Pa) | Efficiency(class) | Model Of Filter Media |
| TR-HXT-1 | 295×295×46mm 12”×12” ×13/4” |
800m³/h | 40Pa | ≥80% Adsorption efficiency |
Black belt activated carbon filter cotton Activated cabron particles |
| TR-HXT-2 | 495×295×46mm 20”×12” ×13/4” |
1300m³/h | |||
| TR-HXT-3 | 495×495×46mm 20”×20” ×13/4” |
2200m³/h | |||
| TR-HXT-4 | 595×295×46mm 24”×12” ×13/4” |
1600m³/h | |||
| TR-HXT-5 | 595×495×46mm 24”×20” ×13/4” |
2700m³/h | |||
| TR-HXT-6 | 595×595×46mm 24”×24” ×13/4” |
3200m³/h |
* Customizable Size
Product Parameters
|
item |
value |
|
Applicable Industries |
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
|
Video outgoing-inspection |
Provided |
|
Machinery Test Report |
Provided |
|
Warranty of core components |
Not Available |
|
Core Components |
media |
|
Condition |
New |
|
Efficiency |
70% |
|
Construction |
Bag Filter |
|
Porosity |
5 Micron |
|
Place of Origin |
China |
|
Province |
Sichuan |
|
Brand Name |
TRAIRF |
|
Dimension(L*W*H) |
595*495*200mm*8p |
|
Weight |
2KG |
|
Warranty |
Unavailable |
|
Product name |
Carbon Activated Bag Air Filters for HVAC System |
|
Type |
Bag Filter |
|
Other name |
filtros de carbono |
|
Filter Media |
carbon activated media filter |
|
Application |
HVAC System |
|
Color |
Black |
|
Size |
595*495*200mm*8p,customiztion |
|
Structure |
Pleated pocket filters |
|
Feature |
Remove odour,strong adsorption ability |
|
Customization |
Available |
1. FCL Shipment Order, using 5 layers carton case.
2. LCL Shipment order, using wooden case package outside.
3. According to customer's requirements.
