Product Paramenters
Bag air filter parameters have model, outside dimensions, rated air flow, initial resistance and efficiency. The size of the product can be determined according to customer requirements. There are standard size and non-standard size, in order to meet a certain number of requirements on the customer can request customization.
Model | Outside Dimensions(mm) | Rated Air Flow(m³/h) | Initial Resistance(Pa) | Efficiency(class) | Model Of Filter Media | Pockets |
TR-ZXD-P1 |
495×295×500mm 20”×12” ×20” |
1000 | 50-130 Pa |
45% F5 65% F6 85% F7 95% F8 99% F9 colorimetric |
F5 White F6 Green F7 Pink F8 Yellow F9 Yellow |
5 |
TR-ZXD-P2 |
495×295×500mm 20”×12” ×20” |
1800 | 5 | |||
TR-ZXD-P3 |
595×295×500mm 24”×12” ×20” |
1300 | 6 | |||
TR-ZXD-P4 |
595×595×500mm 24”×24” ×20” |
2200 | 6 | |||
TR-ZXD-P5 |
495×295×600mm 20”×12” ×24” |
2600 | 8 | |||
TR-ZXD-P6 |
495×495×600mm 20”×20” ×24” |
1200 | 5 | |||
TR-ZXD-P7 |
495×295×600mm 20”×12” ×24” |
2200 | 5 | |||
TR-ZXD-P8 |
595×295×600mm 24”×12” ×24” |
1600 | 6 | |||
TR-ZXD-P9 |
595×495×600mm 24”×20” ×24” |
2700 | 6 | |||
TR-ZXD-P10 |
595×595×600mm 24”×24” ×24” |
3200 | 8 |
* Customizable Size
Product Materials, features, specifications
Size: 595*595*600mm
Pocket: 6 Pockets
External frame: Aluminum alloy frame
Filter media: New composite non-woven fabric
Color: pink
Maximum service temperature: 80℃
Maximum humidity:80%
*Long service life
*Large dust holding capacity
*Can be reused many times*Small resistance, high air volume, low wind speed
Widely used in air conditioning system intermediate filtration;
Clean room fresh air system, etcs.
Details Package: in carton
According to Customers' requirement
Shipping: Sample order:1-2days
