Place of Origin:
Sichuan, China
Brand Name:
TRAIRF
Contact Us
item |
value |
Applicable Industries |
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company |
Video outgoing-inspection |
Provided |
Machinery Test Report |
Provided |
Warranty of core components |
Not Available |
Condition |
New |
Efficiency |
45-95% |
Construction |
Bag Filter |
Porosity |
1 Micron |
Place of Origin |
China |
Province |
Sichuan |
Brand Name |
TRAIRF |
Dimension(L*W*H) |
495*495*500mm *6Pokcets |
Weight |
1KG |
Warranty |
Unavailable |
Type |
Compact |
Filter Material |
Nonwoven Fabric , Melt-blown |
Frame |
Galvanized Steel; Aluminium Alloy |
Color |
White |
Initial Pressure |
50Pa-65 Pa |
Working Highest Temperature |
80℃ |
Humidity |
80% |
Product Parameters
Middle Efficiency Synthetic Fiber Pocket parameters have model, outside dimensions, rated air flow, initial resistance and efficiency and so on. The size of the product can be determined according to customer requirements. There are standard size and non-standard size, in order to meet a certain number of requirements on the customer can request customization.
Model |
Outside Dimensions(mm) |
Rated air flow(m³/h) |
Initial resistance(Pa) |
Efficiency |
Model of filter media |
Pockets |
TR-ZXD-P1 |
495*295*500mm 20”×12” ×20” |
1000m³/h |
50-130Pa |
45% F5 |
F5 |
5 |
TR-ZXD-P2 |
495*295*500mm 20”×12” ×20” |
1800m³/h |
5 |
|||
TR-ZXD-P3 |
595*295*500mm 24”×12” ×20” |
1300m³/h |
6 |
|||
TR-ZXD-P4 |
595*595*500mm 24”×24” ×20” |
2200m³/h |
6 |
|||
TR-ZXD-P5 |
495*295*500mm 20”×12” ×24” |
2600m³/h |
8 |
|||
TR-ZXD-P6 |
495*495*500mm 20”×20” ×24” |
1200m³/h |
5 |
|||
TR-ZXD-P7 |
495*295*500mm 20”×12” ×24” |
2200m³/h |
5 |
|||
TR-ZXD-P8 |
595*295*500mm 24”×12” ×24” |
1600m³/h |
6 |
|||
TR-ZXD-P9 |
595*495*500mm 24”×20” ×24” |
2700m³/h |
6 |
|||
TR-ZXD-P10 |
595*595*500mm 24”×24” ×24” |
3200m³/h |
8 |
* Customizable Size
Application
Air-conditioning filter system intermediate filtration, precision clean Room Clear Room of secondary filtration, high efficiency filter from the filter;
Local prefiltering efficient filter; Large air compressor filter.
Offices, meeting rooms, hospitals, shopping malls, airports and other large-scale civil building ventilation and air conditioning system.
Ordinary industrial workshop or clean room filter's central air conditioning and ventilation system.
Clean air return system.
Electronic technology, medicine and health care, biological products, food and beverage, electrical and mechanical engineering equipment, precision instrument, metallurgy, chemical industry, coating, air conditioning, printing, environmental protection, etc.
