Place of Origin:
Sichuan, China
Brand Name:
TRAIRF
Contact Us
Features :
1.High efficiency for H13,h14,is the finally filtration in clean room that use for filter the particles more than 0.3um.
2.Large dust holding capacity ,the filter media adopts the ultra-thin glass fiber, the hot melt glue spacing each pleats in regular so that achieve high dust volume.
3.Frame: stainless steel, aluminum alloy, galvanized plate
4.Filter media: filter cotton,glass fiber, synthetic fiber, Polyester
5.Sealant around the media prevent the air filter is without any air leaking.
6.HEPA filter with metal screens,prevent the media is without any damage.
7.Light weight for easy to install.
Parameters:
|
Model
|
Dimensions(mm)
|
Airflow(m³/h)
|
Initial Resistance(Pa)
|
Efficiency(%)(0.3um)
|
Dust Capacity(g)
|
|
TR-YCGX-1
|
610*610*50
|
700
|
≤220 or ≤140 HV
|
≥ 99.99
|
450
|
|
TR-YCGX-2
|
915*610*50
|
1000
|
≤220 or ≤140 HV
|
≥ 99.99
|
680
|
|
TR-YCGX-3
|
1220*610*50
|
1400
|
≤220 or ≤140 HV
|
≥ 99.99
|
900
|
|
TR-YCGX-4
|
610*610*69
|
1000
|
≤220 or ≤140 HV
|
≥ 99.99
|
560
|
|
TR-YCGX-5
|
915*610*69
|
1500
|
≤220 or ≤140 HV
|
≥ 99.99
|
840
|
|
TR-YCGX-6
|
1220*610*69
|
2000
|
≤220 or ≤140 HV
|
≥ 99.99
|
1120
|
|
TR-YCGX-7
|
610*610*80
|
1200
|
≤220 or ≤140 HV
|
≥ 99.99
|
650
|
|
TR-YCGX-8
|
610*610*90
|
1400
|
≤220 or ≤140 HV
|
≥ 99.99
|
750
|
|
TR-YCGX-9
|
610*610*100
|
1600
|
≤220 or ≤140 HV
|
≥ 99.99
|
850
|
|
TR-YCGX-10
|
1170*570*69
|
1800
|
≤220 or ≤140 HV
|
≥ 99.99
|
1000
|
|
TR-YCGX-11
|
1170*570*80
|
2200
|
≤220 or ≤140 HV
|
≥ 99.99
|
1250
|
|
TR-YCGX-12
|
1220*610*90
|
2500
|
≤220 or ≤140 HV
|
≥ 99.99
|
1300
|
|
TR-YCGX-13
|
1220*610*90
|
2800
|
≤220 or ≤140 HV
|
≥ 99.99
|
1500
|
|
TR-YCGX-14
|
1220*610*100
|
3200
|
≤220 or ≤140 HV
|
≥ 99.99
|
1700
|
* Customizable Size
